Diamond blades for hollowcore and precast concrete saws
Diamond saw blades for hollowcore slab saws and precast concrete production, 32″ to 55″ (800–1400 mm), in kerf widths from 6.5 to 10 mm.
6.5 mm
7.5–8 mm
9–10 mm
DIAMETER:
32"
34"
36"
KERF:
.256"
ARBOR:
5-1/8"+6
- Diamond saw blades for hollowcore slab saws and precast concrete production.
- Diameters 32"–55" (800–1400 mm); other sizes made to order.
- Kerf widths 6.5 mm (.256"), 7.5 mm (.295"), 8 mm (.312"), 9 mm (.350") and 10 mm (.394").
- Segment height 10 mm standard; 12, 14 and 15 mm made to order.
- Arbors: 60 mm + 2 pins, 60 mm + 1 pin, 60/50 mm + 2 pins, 2" + 1, 5-1/8" + 6 and 60 mm/2" + 1.
- Wet cutting recommended.
| Kerf group | OD | Kerf | Arbor | Part No. |
|---|---|---|---|---|
| 6.5 mm | 32″ | .256″ | 5-1/8″+6 | AS013217 |
| 6.5 mm | 34″ | .256″ | Per order | Made to order |
| 6.5 mm | 36″ | .256″ | 60+1 | AS011552 |
| 7.5–8 mm | 36″ | .312″ | 60+2 | AS008297 |
| 7.5–8 mm | 36″ | .312″ | 60/50+2 | AS011066 |
| 7.5–8 mm | 40″ | .312″ | 60+2 | AS012419 |
| 7.5–8 mm | 40″ | .312″ | 2″+1 | AS012204 |
| 7.5–8 mm | 41″ | .295″ | Per order | Made to order |
| 7.5–8 mm | 44″ | .312″ | 60+2 | AS007408 |
| 7.5–8 mm | 48″ | .312″ | 60+2 | AS011092 |
| 9–10 mm | 52″ | .350″ | 60/2″+1 | AS013050 |
| 9–10 mm | 53″ | .350″ | Per order | Made to order |
| 9–10 mm | 55″ | .394″ | Per order | Made to order |
